An Example Workflow

Written By Kamayani Gupta

Applying Graph Neural Networks for Protein–Protein Interaction Prediction

Predicting protein–protein interactions is critical for understanding cellular function and discovering drug targets. A graph neural network model can learn patterns from known interactions and protein features to predict new potential interactions.

Step 1: Data Collection and Preprocessing

  • Collect protein data: Obtain protein sequences, known interaction pairs (edges), and any additional features such as structural annotations or functional domains.

  • Build initial graph: Represent proteins as nodes in a graph. Known interactions form edges between nodes. Node features may include amino acid sequence embeddings (e.g., from pretrained language models like ProtBert) or structural descriptors.

  • Prepare labels: Label edges as positive (known interaction) or negative (non-interacting pairs sampled carefully to avoid bias).

  • Data splitting: Split data into training, validation, and test sets, ensuring no information leakage (e.g., proteins in the test set should not appear in training to evaluate generalization).

Step 2: Feature Engineering

  • Sequence embeddings: Use pretrained protein language models (e.g., ProtBert, ESM) to generate numerical representations for each protein node.

  • Node features: Concatenate embeddings with other available features, such as protein length or subcellular localization.

  • Edge features (optional): If available, incorporate features describing known interaction types or experimental confidence scores.

Step 3: Model Architecture Selection

  • Choose GNN type: Common choices include Graph Convolutional Networks (GCNs), Graph Attention Networks (GATs), or GraphSAGE. For PPI prediction, GCNs have been successfully applied.

  • Define input and output: Input is the protein graph with node features. The model outputs edge probabilities indicating interaction likelihood.

  • Loss function: Use binary cross-entropy loss on labeled edges.

Step 4: Model Training

  • Train model: Optimize model parameters on the training set. Monitor performance on validation set to avoid overfitting.

  • Hyperparameter tuning: Experiment with number of layers, hidden dimensions, learning rate, and dropout.

  • Regularization: Apply dropout and weight decay to improve generalization.

Step 5: Model Evaluation

  • Metrics: Evaluate using precision, recall, F1-score, and area under the ROC curve (AUC-ROC). Precision-recall curves are particularly informative in imbalanced datasets.

  • Test set evaluation: Assess performance on held-out proteins to confirm ability to generalize to unseen data.

Step 6: Interpretation and Validation

  • Interpret model predictions: Use techniques like node-level attention weights or integrated gradients to understand which features or network regions drive predictions.

  • Biological validation: Cross-reference high-confidence predicted interactions with external databases or literature.

  • Experimental validation: Prioritize top candidates for laboratory experiments.

Step 7: Deployment and Integration

  • Model deployment: Package the model into an accessible tool or API for use by researchers.

  • Integration: Incorporate predicted interactions into broader biological networks for downstream analysis such as pathway enrichment or drug target prioritization.

Tools and Libraries
